1200KW 1500KVA Cummins Generator
About The Genset
Beidou 1200KW Cummins diesel generator adopts KTA50 series original Chongqing Cummins diesel engine, which is world-renowned for its performance and widely regarded as the most robust and cost-effective diesel engine in the power range of the generator set market. Cummins has invested more than 140 million US dollars in China. As a foreign investor in China's engine industry, Cummins has eight joint ventures and wholly-owned manufacturing enterprises in China. Among them, Dongfeng Cummins produces B, C and L series diesel engines, and Chongqing Cummins produces M, C and L series diesel engines. N and K series diesel engines. The products comply with ISO 3046, ISO 4001, ISO 8525, IEC 34-1, GB1105, GB/T 2820, CSH 22-2, VDE 0530 and YD/T 502-2000 "Technical Requirements for Diesel Generator Sets for Communication" and other standards. Beidou 1200KW 1500KVA Cummins powered diesel generator set can continuously output 1200KW 1500KVA power for 12 hours, and the maximum output is 1320KW 1650KVA power in 1 hour. The output frequency is 50Hz or 60Hz, which can be customized according to the customer's region, and choose different models of Cummins diesel engines and motors with different speeds. The power is stable and the power is sufficient. At the same time, enjoy the Cummins global warranty to fully guarantee the sales service for overseas use.
Product Display
| Brand | Beidou Power |
| Model | BD-C1200 |
| Place of origin | Yangzhou, Jiangsu, China |
| Genset power | 1500KVA/1200KW |
| Output current(A) | 2160A |
| Rated AC Voltage(V) | 230/400V;240/440V |
| Frequency | 50HZ;60HZ |
| Power factor | 0.8 (lag) |
| Line system | Three-phase |
| Noise level(dB) | ≤102 |
| Fuel consumption at 100% load | ≤192L/h |
| Dimensions (mm) | 5100*2200*2750mm |
| Weight (kg) | 14000kg |
About Diesel Engine
The diesel engine adopts the internationally renowned brand Cummins
Engine Basics
The KTA50-Series benefits from years of technical development and improvement to bring customers an innovative and future proof diesel engine that keeps pace with ever changing generator set requirements. Recognised globally for its performance under even the most severe climatic conditions, the KTA50-Series is widely acknowledged as the most robust and costeffective diesel engine in its power range for the generator set market.
Coolpac Integrated Design - Products are supplied complete with cooling package and air cleaner kit for a complete power package. Each component has been specifically developed and rigorously tested for G-Drive products, ensuring high performance, durability and reliability.
Aftercooler – Large capacity integral aftercoolers are supplied with cooling water separate from the engine jacket. This provides cooler, denser intake air for more complete combustion and reduced engine stresses for longer life and low exhaust emissions
| Diesel engine model | KTA50-GS8 |
| Engine Power | 1429KW |
| Type | Four stroke and mid-cooling |
| Four stroke and mid-cooling | water cooling |
| Number of cylinders | 16/in V |
| Bore (mm) × Stroke (mm) | 159*159 |
| Lubricant capacity(L) | 204 |
| Compression ratio | 14.9：1 |
About Alternator
All-Cooper：
1. Compared with aluminum, copper has less resistance and less loss，the all-copper generator is more durable.
2.Pure copper wire generators are more energy efficient.
3.Pure copper core generator is quieter.
Brushless：
Brushless generator motors are easier to maintain than brushed generators with less moving parts to clean, repair or replace. Fewer moving parts also means less wear and tear on the alternator. The absence of brushes eliminates overheating issues and breakdowns as well.
Alternator Parameter
| Brand | Stamford;Marathon；Leroy；Beidou Power and so on |
| Power | 1500KVA/1200KW |
| Rated AC Voltage(V) | 230/400V;240/440v |
| Excitation way | Brushless, self-excitation, AVR |
| Rated frequency | 50HZ;60HZ |
| Insulation level | H |
| Degree of protection | IP22;IP23 |
About Controller
Controller adopts computer module with four protection systems, and adopts international famous brands: Smartgen, Deep sea, ComAp and so on.
